Premium Truck Scissor Dock Lift, 5K, 7' x 8'

The price shown does not include shipping. Please Contact Us prior to ordering for a total inclusive price.

This Truck Scissor Dock Lift is engineered and designed for maximum safety & efficiency. The checkered plate deck is made of heavy-gauge steel for years of use. The hydraulic cylinders feature emergency a safety velocity fuse if the line breaks. It comes with an upper travel limit switch and an overload relief valve. The push button control is attached to a 20-foot-long coil cord. The pre-wired control box includes a magnetic starter and an overload fuse. It features high visibility safety yellow removable handrails with fixed toe boards. It also includes beveled toe-guards and electric toe-guards around the perimeter of the platform. The external 6.5 HP 460V, 3-phase, 60 Hz motor can be moved up to 8 feet away from the lift. The motor weighs 300 pounds. Manufactured by Vestil Mfg.

Safety Features:

The electric toe-guard is a patented feature which is essential to the safety of your personnel. The guard is made of L-shaped aluminum extrusion and it hangs below the entire perimeter of the deck. If the Scissor Dock is lowered while an object such as a person’s hand or foot is in its path, the guard will be triggered, and it will electrically stop the table from lowering further. Once the object is removed, the table will again be operable. Without these toe-guard provisions, scissor tables do not meet OSHA or ANSI standards and are dangerous to operate.

• Platform Size is 84" x 96".
• Lowered Height is 8", Raised Height is 68".
• Weight Capacity is 5000 Pounds.
• Overall Frame is 62" x 93".
• Weight is 3,059 Pounds.
• Free Shipping Exempt due to shipping size and weight.

Available upon request:

• Approval Drawings
• Warranty
• Testing Certificate
